Detalhes do produto:
|
Applicable Industries: | Garment Shops, Farms, Home Use, Retail, Food Shop, Printing Shops, Construction works , Food & Beverage Shops, Advertising Company | Showroom Location: | None |
---|---|---|---|
Condition: | New | Power Souce: | AC Motor |
Min. Lifting Height: | 145mm | Fork Length: | 1220mm |
Fork Width: | 122mm | Overall Dimensions: | 2045*820*2087 mm |
Warranty: | 1 Year | Machinery Test Report: | Provided |
Video outgoing-inspection: | Provided | Warranty of core components: | 1 Year |
Core Components: | Motor, Bearing, Gearbox | Weight (KG): | 835 kg |
Type: | Powered Pallet Truck | After-sales Service Provided: | Overseas third-party support available |
Product name: | 2 ton counterbalance stacker | controller: | USA Curtis brand |
drive motor: | AC motor | Lift motor: | DC motor |
Mast: | Duplex/ Triplex full free mast | Charger: | included |
Marketing Type: | New Product 2020 | Port: | Shanghai, Qingdao,Tianjin,Guangzhou, |
Destacar: | Empilhadeira de paletes de armazenagem,Empilhador de contrapeso de 2 toneladas,Empilhador de contra-equilíbrio de armazém |
Tipo de unidade
|
|
Dispositivo elétrico (bateria)
|
Tipo de operação
|
|
Walkie-talkie
|
Carga nominal
|
Quilos
|
1500
|
Distância do centro de carga
|
mm
|
600
|
Peso (incluindo bateria)
|
Quilos
|
835
|
L*W*H
|
mm
|
2045*820*2087
|
Tamanho do garfo
|
mm
|
60*170*1070
|
Altura de elevação
|
mm
|
3000
|
Comprimento até à face dos garfos
|
mm
|
878
|
Largura total dos garfos
|
mm
|
570/695
|
Largura do corredor para paletes 800 x 1200
|
kW
|
2450
|
Voltagem da bateria/capacidade nominal
|
V/Ah
|
24/200
|
Peso (bateria)
|
Quilos
|
160
|
Velocidade de deslocamento com carga total/sem carga
|
kW/h
|
5.8/6
|
Velocidade de elevação com carga total/sem carga
|
m/s
|
0- O que é?16
|
Velocidade de redução com carga total/sem carga
|
m/s
|
0.15/0.16
|
Radius de rotação
|
mm
|
1605
|
